Continuous module-type tunnel for garments finishing. In function of its composition and the type of work to do, it can produce from 500 to 800 pieces per hour. the tunnel is composed and complete with:

• an automatic right load station for single garments complete with gamrents lack signal; and an unload station
• variable-speed chain conveyor (controlled by an inverter) with hooks spaced out at 317 mm. intervals
• one steaming chamber
• one variable-temperature ventilation chamber and variable capacity through inverter
• steaming quantity regulation
• steaming humidity adjustment
• garments falling signal
• pillows for steam containment in the steaming chamber
• programming and regulation with TCW "7 programmer:
  - short or long garments with independent control low steaming
  - continuous or alternate garments loading
  - variable and programmable garments transport speed
  - partial and totalizer garment counter
  - variable extractor for extra steam canalization (inverter)
  - registration up to 99 programs

SEAM SEALING MACHINE WITH FIXED BOTTOM COLUMN

The machine is complete with:

• motorized rollers with independent speed and differential effect
• nozzle adjustable on 3 axis position
• 25 mm motorized upper roller for 22 mm tape
• 25 mm motorized bottom roller for 22 mm tape
• possibility to select hot guide for tape (no tape cutter)
• possibility to select cold guide and front cutter
• adapted to be fitted with electronic metering device 902.01
• adapted to be fitted with tape pre-lamination device 903.01
• tape spool support
• lighting lamp for working station.
• colour Touch Screen for parameter setting

Electropneumatic machine for SIMULTANEOUS PRESSING OF BODY, YOKE AND SHOULDERS OF SHIRTS, complete with:

• two dummies with vacuum, movable upper side (shoulders and yoke) and side adjustment by pneumatic inflatable bags
• electrically heated plates
• electronic temperature control with independent adjustment between front and back plates
• adjustable separate pressing pressures for body, shoulders and inflatable bags
• manual water spraying gun
• built-in vacuum unit of 3 Kw, with silenced exhaust
• safety guard device - programmer TCW color terminal for the programming of 7" with USB and Wi-Fi, for the following functions:
  - body pressing
  - shoulder pressing
  - inflatable bags control
  - water spraying control (when foreseen)
  - production counter

CONTINUOUS BELT FUSING MACHINE, split in the following sections:

• cold loading belt with inverter control
• length 1100 mm
• fusing heated area with no.2 cylinders drive
• length 1000 mm
• unloading belt with inverter control
• lenght 1060 mm
• the machine is already adapted to be connected with the automatic loader Mod. 985 and unloader Mod. 978
• useful working area: 1000 mm
• 7" color terminal TCW for parameters setting complete with USB port and Wi-Fi connection. It is also adapted to control by video the loding and unloding devices
• automatic switch off
• fusing pressure from 0 to 6 Ate with 2 cylinders
• programmable belt speed from 2 to 10 mt/min and controlled by inverter
• no.2 programmable temperature controls
• automatic light signal of "machine ready" or any eventual malfunctioning
• four belts cleaning devices, two inner and two outer
• detachment of fused fabric by carbon blade

HEATING The machine heating is by steam only. The max. temperature which can be achieved on the fabric is 10°C lower than the steam nominal temperature
