The FX25s unit is automatic folding and stacking machine for readymade garments (shirts, sweaters, t-shirts, polo shirts, etc.), designed to fold almost any type of garment quickly, accurately, and quietly. FX25s offer a program for easy packing in a plastic bag and a program for stacking and easy organising of the folded garments.
The FX model is suitable for customers requiring a small folding unit with a stacking mechanism and the capability of preparing the folded garments for manual packing in plastic bags. The FX25s machine can be easily and precisely adapted to any folding requirements, it is robustly built and require minimum maintenance. Moreover it does not require any special installation
(plug & play), it has low power and air consumption, and it is very easy to operate.

TECHNICAL SPECIFICATIONS

• DIMENSIONS L-W-H: 106x93x83cm
• NET WEIGHT 130kg
• POWER SUPPLY: 100-240V AC 50-60Hz
• POWER: 0.24kW
• AIR PRESSURE: 6bar
• AVERAGE AIR CONSUMPTION 36L/min
• DIMENSIONS OF FOLDED GARMENT: WIDTH: min18cm max 30cm LENGTH: max 39cm
• MAXIMUM OUTPUT:
  • FOLDING & PACKING: 2.500pcs/8h
  • FOLDING & STACKING: 3.500pcs/8hOPERATOR:
• 1 Person



The SB50 & SB50M automatic machines seal the self-tape plastic bags that contain the garments,
which come folded and packed from the STP1000 folding machine and the PV40 bagging machine.

SB50 is versatile and can accommodate a wide range of bag sizes, making it suitable for packaging different types of garments. It
is also designed with ease of use in mind, featuring a user-friendly interface that allows operators to adjust settings and monitor
the packaging process. The machine is constructed with high-quality materials to ensure durability and longevity. It is also designed
for easy maintenance, with easily accessible parts that can be quickly and easily replaced if needed.

TECHNICAL SPECIFICATIONS

• DIMENSIONS L-W-H: SB50: 190x118x123cm / SB50M: 251x118x123cm
• NET WEIGHT: SB50: 265kg / SB50M: 280kg
• POWER SUPPLY: 200-400V AC 50-60Hz
• POWER: 1.1kW
• AIR PRESSURE: 6bar
• AVERAGE AIR CONSUMPTION: SB50 & SB50M: 120L/min
• WIDTH OF BAG: 16-38cm
• MAXIMUM GARMENT THICKNESS: 10cm
• OPERATOR: 1 Person

Accessories

• ST10 STACKING MECHANISM [see page 28]
• MT1775 CONVEYOR BELT FOR GARMENTS

PV40 is a new automatic bagging machine for readymade garments. It is the evolution of the previous PV38 model, with targeted improvements and a detachable conveyor belt (MT1775), according to the customer needs. The output of PV40 depends on the production speed of STP1000or the speed at which an operator can feed the clothes into the machine when it is used as a standalone, with the GA1 garment alignment accessory.

The new PV40 automatic bagging machine packs the garments that come folded from the STP1000 automatic folding machine in polyethylene (PE) and polypropylene (PP) bags, in the shape of a folder.

If more than one garments are to be placed in the bag, PV40 must be used independently of STP1000 by installing the GA1 accessory, and the operator must manually place the garments on the machine.

PV40 is offered either as a standalone unit or as a part of a folding and packing machine set. When the PV40 unit is the last station of a machine set, the machine is delivered with the MT1775 conveyor belt and designated PV40M.The PV40 & PV40M machines are robustly built and require minimum

TECHNICAL SPECIFICATIONS

• Dimensions L*W*H:
  • PV40: 92*68*130cm
  • PV40M: 176*68*130 cm
• Net weight:
  • PV40: 115Kg
  • PV40M: 130Kg
• Power supply: 210-400V AC 50-60 Hz
• Power capacity: 0.33Kw
• Air pressure: 6 bar
• Average Air consumption: 70 L/min
• Bag width: 18-38 cm
• Flap length (Lf): 5cm minimum
• Maximum garment thickness: 6cm
• Bag capacity: 80-100
• Operator: 1 person
• CE

Accessories

• GA1 GARMENT ALIGNMENT
• MT1775 CONVEYOR BELT FOR GARMENTS

LD70 is a new automatic machine designed for attaching adhesive strips and labels on garments. The purpose of the labels is to inform the final consumer regarding the size of the garment or to provide other important information, as deemed appropriate by the garment manufacturer.

The LD70 may be installed after the automatic STP1000 folding machine, to receive folded garments and attach the labels or adhesive strips on them. Moreover, the LD70 automatic labelling machine may also operate as a standalone unit, manually fed by an employee with folded garments.

The output of the LD70 machine depends on the production speed of the STP1000 folding machine and its operator or simply on the speed of its operator, when the machine is used as a standalone

TECHNICAL SPECIFICATIONS

• Dimensions L*W*H: 144*80*139cm
• Net Weight: 225 Kg
• Power Supply: 210-400V AC 50-60Hz
• Power: 1,44Kw
• Maximum Folded Thickness: 10cm
• Label Material Characteristics: Label lifespan: Labels preserve their characteristics for 12 months if the necessary storage conditions are met. Conditions for material usage: Storage conditions: 10⁰C – 25⁰C, 40-60% humidity and avoid exposure to sunlight or infrared radiation.
